The most complete list of clutch cover and disc almost cover all forklifts

1.Composition of friction forklift clutch

The friction clutch is the most widely used and the oldest type of clutch. It’s basically composed of four parts: the driving part, driven part, the pressing and operating mechanism. The driving and driven parts and the pressing mechanism are to ensure that the clutch is in a connected state and can transmit power. While the operating mechanism of the clutch is mainly a device for separating the clutch.

Stepping on the clutch pedal during the separation process first eliminates the clutch free clearance in the free stroke. Then a separation clearance is generated in the working stroke and the clutch is separated. In the joining process, gradually loosen the clutch pedal, the pressure plate moves forward under the action of the spring. First, eliminate the separation clearance, and apply enough pressure on the working surface of clutch cover, clutch disc and flywheel. Afterward, the release bearing moves backward under the return spring’s action, creating a free gap and the clutch is joined

2.Working principle of friction forklift clutch

The flywheel is the clutch driving part, the clutch plate and driven disc hub are connected to the input shaft by sliding splines. The compression spring presses the clutch disc on the flywheel, the engine torque relies on the friction between the flywheel and clutch disc, which is transferred from the flywheel to the clutch disc, and then gearbox, finally to the wheels.

The clutch cover and disc should always be joined to transfer power. The driver stepped on the clutch pedal. the fork stuck in the drum ring groove of the clutch disc pushes the clutch disc to move to the right. The driven plate is separated from the flywheel to cut off the power transmission. Slowly release the pedal, so that the clutch disc and flywheel gradually joined, can restore power transmission. The joining process is from the two speed is not equal, gradually to the same speed state. When the clutch is fully joined without slipping, the forklift’s speed is directly proportional to the speed of the engine.
